Hi. My name is George. Some of you may know me from lurking around the forums. I drive a 2003 NB. I have a build thread over on CR but its been mostly non boost related. Im just going to give you guys the low down on whats been done so far.

First....heres my car. Its silver. This was taken at Thunderhill.


It has a 6spd, 3.9 torsen lsd, ls package car I assume. It came with the hard dog roll bar. I would like to weld back in diagonals eventually. I got a used set of tein street flex coilers with edfc before I knew about what good coils were. 9kg front springs.

Things I have installed in the car already.
MS3 from Rev/TSE:

Yes I have a long *** last name.

Bracket for ECU:


LC2 Wideband:


CX Racing Intercooler kit bought from member on here(not piped in, just mounted):


CAN Module:


And Flow Force EV-14 640cc Injectors:


Today I picked up the actual turbo kit:




Colors

Upper Down Pipe:



And not pictured is all the "accessories" (oil/water lines, studs, etc.)

I would like to give a shout out to Andrew from TSE for putting up with my noobness and helping me out through the way. Thanks turbo daddy. We still got a long way to go.

Old 08-24-2016 | 03:58 AM
  #2
Lokiel's Avatar
All-round "Good Guy"

Joined: Dec 2009
Posts: 1,014
Total Cats: 260
From: Brisbane, AUSTRALIA
Default

Y U got downpipe already?

Because not yet mated to flange?

Me waiting long-time!
Old 08-24-2016 | 02:46 PM
  #3
icantlearn's Avatar
Thread Starter
Elite Member

Joined: Sep 2015
Posts: 1,939
Total Cats: 117
From: San Jose, CA
Default

Originally Posted by Lokiel
Y U got downpipe already?

Because not yet mated to flange?

Me waiting long-time!
This is just the upper down pipe. The lower half should be in next week.
Old 08-24-2016 | 02:49 PM
  #4
Savington's Avatar
Former Vendor
iTrader: (31)

Joined: Nov 2006
Posts: 15,442
Total Cats: 2,104
From: Sunnyvale, CA
Default

Originally Posted by Lokiel
Y U got downpipe already?
Half a downpipe is better than nothing, but I think I might get death threats if I send out "Downpipe tracking!" emails and only half a DP is in there. NB lowers are in production and should be shipping this week with any luck.
Old 08-24-2016 | 10:39 PM
  #5
blackdbl9NB's Avatar
Newb

Joined: Oct 2012
Posts: 39
Total Cats: 3
From: Sioux Falls SD
Default

Want more! My NB1 is begging for boost, and I have been drooling over the TSE kit for a while now.
Old 08-25-2016 | 04:00 AM
  #6
codrus's Avatar
Elite Member

Joined: Mar 2007
Posts: 5,187
Total Cats: 859
From: Santa Clara, CA
Default

Shiny! Good to meet you at the NCR meet this evening!

--Ian
Old 08-25-2016 | 12:50 PM
  #7
icantlearn's Avatar
Thread Starter
Elite Member

Joined: Sep 2015
Posts: 1,939
Total Cats: 117
From: San Jose, CA
Default

Originally Posted by blackdbl9NB
Want more! My NB1 is begging for boost, and I have been drooling over the TSE kit for a while now.
I will update the tread this evening with the extra goodies that I got. Im very exited too!
Old 08-25-2016 | 12:51 PM
  #8
icantlearn's Avatar
Thread Starter
Elite Member

Joined: Sep 2015
Posts: 1,939
Total Cats: 117
From: San Jose, CA
Default

Originally Posted by codrus
Shiny! Good to meet you at the NCR meet this evening!

--Ian
It was good to meet you too!
Old 08-26-2016 | 02:15 PM
  #9
icantlearn's Avatar
Thread Starter
Elite Member

Joined: Sep 2015
Posts: 1,939
Total Cats: 117
From: San Jose, CA
Default

I picked up 3 225/45/15 RS3s for dirt cheap. They appear to have about 90% tread. Ill get a new one from tire rack.

I needed to block off the BOV port on my intercooler pipe so I cut this out from a sheet of steel that was laying around.

After some time on the bench grinder and two holes. Still needs some refining and a lick of paint.

Inconel stud kit. Attempted to install into the manifold. I was suprised to read 10ft lbs on the instructions for these. I hope they dont come out of the manifold.

Inconel stud. So nice.

Old 08-27-2016 | 05:14 AM
  #10
Der_Idiot's Avatar
Senior Member
iTrader: (2)

Joined: Nov 2007
Posts: 1,489
Total Cats: 28
From: Saint Paul, MN
Default

Nice build so far! Welcome to the EFR club, is that a 6258? The brake fluid didn't like the proximity to my downpipe, watch your brake fluid when you start tracking it. My (custom) downpipe was bent as tightly as he could to keep it away from things but it is still fairly close to the MC. I cooked my fluid after a few days in the high 90s.
Old 08-27-2016 | 12:04 PM
  #11
icantlearn's Avatar
Thread Starter
Elite Member

Joined: Sep 2015
Posts: 1,939
Total Cats: 117
From: San Jose, CA
Default

Originally Posted by Der_Idiot
Nice build so far! Welcome to the EFR club, is that a 6258? The brake fluid didn't like the proximity to my downpipe, watch your brake fluid when you start tracking it. My (custom) downpipe was bent as tightly as he could to keep it away from things but it is still fairly close to the MC. I cooked my fluid after a few days in the high 90s.
Yep its a 6258. I picked up some heat wrap so I'm going to wrap everything close to the turbo. I have considered ceramic coating the downpipe but I want to see how the car does with just the heat wrap first.
Old 08-27-2016 | 08:57 PM
  #12
Der_Idiot's Avatar
Senior Member
iTrader: (2)

Joined: Nov 2007
Posts: 1,489
Total Cats: 28
From: Saint Paul, MN
Default

The manifold looks great coated, glad I sent it to swain. I get a lot of comments from folks since it's the second thing they see after the shiny turbo lol.
Old 09-06-2016 | 06:18 PM
  #13
icantlearn's Avatar
Thread Starter
Elite Member

Joined: Sep 2015
Posts: 1,939
Total Cats: 117
From: San Jose, CA
Default

So I picked up a bunch of intercooler couplers last week in preparation for the turbo install.
URL=http://s935.photobucket.com/user/enzoloco1/media/image_zps858vjfwx.jpeg.html][/URL]

Friday of last week. The turbo install began.

Out came the airbox and header heat shield. You can see in the pic I was mocking up the intercooler piping. I need to figure out how to keep it from crushing the upper radiator house.


Here is a pic showing where I routed the driver's side intercooler piping from the engine bay.


Out came header and on went valve cover breather


I managed to unscrew the whole manifold stud while removing the header. The nut was frozen on.


Oil pan drilled and tapped. Was kinda nervous while doing this.


I will update with more pics tonight.







Old 09-07-2016 | 11:04 AM
  #14
borka's Avatar
Elite Member
iTrader: (1)

Joined: Mar 2014
Posts: 1,552
Total Cats: 196
From: Jacksonville, FL
Default

on the cold side, if you use a silicone 90 degree bend, instead of the reducer and then a 90 degree metal pipe, it will clear the radiator hose better.

also i cut the radiator hose a few inches shorter at the radiator end, so it doesnt arch as much towards the intercooler pipe.




Old 09-07-2016 | 11:52 AM
  #15
icantlearn's Avatar
Thread Starter
Elite Member

Joined: Sep 2015
Posts: 1,939
Total Cats: 117
From: San Jose, CA
Default

Originally Posted by borka
on the cold side, if you use a silicone 90 degree bend, instead of the reducer and then a 90 degree metal pipe, it will clear the radiator hose better.

also i cut the radiator hose a few inches shorter at the radiator end, so it doesnt arch as much towards the intercooler pipe.
I was just using what I got with the intercooler. I will try cutting the hose. Thanks!
Old 09-07-2016 | 12:49 PM
  #16
icantlearn's Avatar
Thread Starter
Elite Member

Joined: Sep 2015
Posts: 1,939
Total Cats: 117
From: San Jose, CA
Default

(spooky effect lighting)


Here is cold side intercooler piping for anyone that was interested

Last edited by icantlearn; 09-07-2016 at 01:06 PM.
Old 09-07-2016 | 01:32 PM
  #17
yossi126's Avatar
Senior Member
iTrader: (6)

Joined: Sep 2013
Posts: 859
Total Cats: -14
Default

Make sure you clear room for a gates 22436.
Old 09-07-2016 | 01:48 PM
  #18
icantlearn's Avatar
Thread Starter
Elite Member

Joined: Sep 2015
Posts: 1,939
Total Cats: 117
From: San Jose, CA
Default

Originally Posted by yossi126
Make sure you clear room for a gates 22436.
Why?
Old 09-21-2016 | 08:25 PM
  #19
Alternative's Avatar
Junior Member

Joined: Jan 2015
Posts: 272
Total Cats: -25
Default

Originally Posted by yossi126
Make sure you clear room for a gates 22436.
it doesn't fit an NB anyhow.

Needs to use the Begi method
Reply
Leave a poscat -1 Leave a negcat
Old 09-22-2016 | 01:05 AM
  #20
icantlearn's Avatar
Thread Starter
Elite Member

Joined: Sep 2015
Posts: 1,939
Total Cats: 117
From: San Jose, CA
Default

Originally Posted by Alternative
Needs to use the Begi method
explain...
