Nothing to see here, just project Sisyphus, move along
#1002
Elite Member
iTrader: (15)
Join Date: Jan 2007
Location: Murfreesboro,TN
Posts: 2,068
Total Cats: 277
![Default](https://www.miataturbo.net/images/icons/icon1.gif)
Do not let them give you a cortisone shot in your tendon. It will cause damage down the road. One of my best friends and mother-in-law both have tendon issues from getting one. They didn't find out until later when they consulted another doctor about on going issues.
#1003
Elite Member
Thread Starter
iTrader: (37)
Join Date: Apr 2010
Location: Very NorCal
Posts: 10,448
Total Cats: 1,900
![Default](https://www.miataturbo.net/images/icons/icon1.gif)
![Ohnoes](https://www.miataturbo.net/images/smilies/ohnoes.gif)
#1004
Elite Member
Thread Starter
iTrader: (37)
Join Date: Apr 2010
Location: Very NorCal
Posts: 10,448
Total Cats: 1,900
![Default](https://www.miataturbo.net/images/icons/icon1.gif)
So I just noticed that Mocal makes the thermostatic oil cooler sandwich plate we all know and love in a 200°F version as well as the 180°F version. (There may also be a 220°F version out there somewhere but I can't find a PN.) I'm actually thinking 200°F is a much better choice based on what I've been reading. Can anyone think of a reason this would be a bad idea?
I'm planning on running the "behind the radiator" configuration that we all seem to be gravitating toward recently.
I'm planning on running the "behind the radiator" configuration that we all seem to be gravitating toward recently.
#1005
![Default](https://www.miataturbo.net/images/icons/icon1.gif)
200 is a great idea. I don't know why more sandwich plates don't use that as standard. I like cooking off the water in my oil while street driving.
Once you're on track in the heat, you're going to be running 220-240 on oil temps anyway, and at those temps 180 or 200 bypass will be fully closed (i.e., all oil going to cooler).
Once you're on track in the heat, you're going to be running 220-240 on oil temps anyway, and at those temps 180 or 200 bypass will be fully closed (i.e., all oil going to cooler).
Last edited by hornetball; 03-25-2015 at 04:17 PM.
#1006
Elite Member
Thread Starter
iTrader: (37)
Join Date: Apr 2010
Location: Very NorCal
Posts: 10,448
Total Cats: 1,900
![Default](https://www.miataturbo.net/images/icons/icon1.gif)
That's pretty much exactly my thinking as well. The 200°F version is like $10 more than the 180°F version so not really a big deal. I think I'm going to go with the 200°F.
I'm still at an impasse as to if I want to keep my sender sandwich plate in place, and if so, if it should be mounted between the mocal and the block, or the mocal and and filter. I can also eliminate it altogether and stick my temp sender in the pan instead.
If my understanding of how the path works is correct, then:
I see merits for each of these locations, but I'm unsure where to put the stupid thing. I've read the comments in Jeffbuc's thread and I've read Savington's "everything you ever wanted to know about oil coolers but were afraid to ask" thread as well, so don't throw links at me
I just need to make a decision and go for it.
Speaking of decisions, I ordered a -10 male flange fitting for the CHRA drain today![Party Kitty](https://www.miataturbo.net/images/smilies/birthday[1].gif)
Slowly but surely I'll get this all plumbed up and happy.
I'm still at an impasse as to if I want to keep my sender sandwich plate in place, and if so, if it should be mounted between the mocal and the block, or the mocal and and filter. I can also eliminate it altogether and stick my temp sender in the pan instead.
If my understanding of how the path works is correct, then:
- Before the mocal gives me the temp before the cooler, possibly the hottest location
- In the pan gives me more of an aggregate temp for the entire system, possibly low due to pan cooling
- After the mocal gives me the temp that is going into the engine, like what the components will actually see
I see merits for each of these locations, but I'm unsure where to put the stupid thing. I've read the comments in Jeffbuc's thread and I've read Savington's "everything you ever wanted to know about oil coolers but were afraid to ask" thread as well, so don't throw links at me
![Giggle](https://www.miataturbo.net/images/smilies/gay.gif)
Speaking of decisions, I ordered a -10 male flange fitting for the CHRA drain today
![Party Kitty](https://www.miataturbo.net/images/smilies/birthday[1].gif)
Slowly but surely I'll get this all plumbed up and happy.
#1008
![Default](https://www.miataturbo.net/images/icons/icon1.gif)
I see merits for each of these locations, but I'm unsure where to put the stupid thing. I've read the comments in Jeffbuc's thread and I've read Savington's "everything you ever wanted to know about oil coolers but were afraid to ask" thread as well, so don't throw links at me
I just need to make a decision and go for it.
![Giggle](https://www.miataturbo.net/images/smilies/gay.gif)
![](https://www.miataturbo.net/images/smilies/smile.gif)
I would do post-cooler, because that's what really matters. The only reason to look at pre-cooler is to tell how well your cooler is working.
--Ian
#1010
Elite Member
Thread Starter
iTrader: (37)
Join Date: Apr 2010
Location: Very NorCal
Posts: 10,448
Total Cats: 1,900
![Default](https://www.miataturbo.net/images/icons/icon1.gif)
You know my crazy, don't tempt me.
Also, I saw you were running with a Lemons team up at Sears last weekend! I (almost) change tires like a bauce. When both my feet are working
I guess I shouldn't volunteer for things at this point.
See, I agree with both of these approaches. That's mah prablem.
The pan is still off the motor at this point so I'm going to ask Gesso if he can weld in an 1/8"NPT bung along with the -10 Male for the turbo return, so the pan for the oil temp will always be an option going forward. Once the 200°F mocal gets here I'll start mocking things up. The nice thing about the plate is I can always change it around if I decide I'm insane. (I'm insane)
Also, I saw you were running with a Lemons team up at Sears last weekend! I (almost) change tires like a bauce. When both my feet are working
![Sad](https://www.miataturbo.net/images/smilies/sad2.gif)
The pan is still off the motor at this point so I'm going to ask Gesso if he can weld in an 1/8"NPT bung along with the -10 Male for the turbo return, so the pan for the oil temp will always be an option going forward. Once the 200°F mocal gets here I'll start mocking things up. The nice thing about the plate is I can always change it around if I decide I'm insane. (I'm insane)
#1011
![Default](https://www.miataturbo.net/images/icons/icon1.gif)
Pre-cooler or in-the-pan gives you a sense of the max temp the oil gets to, which should tell you if the oil is reaching temperatures that will cause it to break down and shorten its life.
--Ian
#1013
![Default](https://www.miataturbo.net/images/icons/icon1.gif)
Come to think of it, senders are cheap. You could install 2 or 3 senders, one gauge, and use a switch. That'd let you leave it on one particular setting but periodically flip to the other one to validate that it has the delta from the first one that you expect it to.
Yeah, a friend of mine runs an E36 there, was looking for drivers, and talked me into doing it. It was... nuts. 180 cars on 2.3 miles of Sears Point is a lot. Still, I had fun!
![](https://www.miataturbo.net/images/smilies/smile.gif)
I didn't know the Mocal plate came in a 200F version, I agree it's a better choice. I'm actually tempted to swap mine.
--Ian
#1014
Elite Member
Thread Starter
iTrader: (37)
Join Date: Apr 2010
Location: Very NorCal
Posts: 10,448
Total Cats: 1,900
![Default](https://www.miataturbo.net/images/icons/icon1.gif)
Mocal Sandwich Plate 20mm Thread w/ 200 Degree T-Stat ~ MOC-SP1FT-HT. They refer to it as the "High Temp" version.
I would assume you could just buy the little pill thing in the thermostat as it is replaceable. Just buy the 200°F replacement rather than the 180°F. I'd ask Racerpartswholesale or Bat-Inc as they seem to be the only distributors in North America. I know Andrew also has Mocal stuff so he might be able to get you a PN as well. Just a couple thoughts
I would assume you could just buy the little pill thing in the thermostat as it is replaceable. Just buy the 200°F replacement rather than the 180°F. I'd ask Racerpartswholesale or Bat-Inc as they seem to be the only distributors in North America. I know Andrew also has Mocal stuff so he might be able to get you a PN as well. Just a couple thoughts
![wink](https://www.miataturbo.net/images/smilies/wink.gif)
#1015
Elite Member
![](/mt2011/images_td/ranks/supporter1.gif)
iTrader: (2)
Join Date: May 2008
Location: Portland, Oregon
Posts: 3,468
Total Cats: 365
![Default](https://www.miataturbo.net/images/icons/icon1.gif)
Mine will be pre cooler so I can accurately compare temps to before the cooler was installed.
I have seen 245 or so oil temps on warmish days. I'd like to see no higher than 230 hot temps once the.cooler is installed.
The multi sender switch deal is intriguing but will have to wait until after my NZ expat adventure I think. Last project for the car this year will be hooking up the oil cooler.
I have seen 245 or so oil temps on warmish days. I'd like to see no higher than 230 hot temps once the.cooler is installed.
The multi sender switch deal is intriguing but will have to wait until after my NZ expat adventure I think. Last project for the car this year will be hooking up the oil cooler.
#1016
Elite Member
Thread Starter
iTrader: (37)
Join Date: Apr 2010
Location: Very NorCal
Posts: 10,448
Total Cats: 1,900
![Default](https://www.miataturbo.net/images/icons/icon1.gif)
Multiple senders and a switch occurred to me as well. I'd put one in the pan and one in the sandwich between the mocal plate and the filter. That should give me all the data I want.
#1017
Elite Member
![](/mt2011/images_td/ranks/supporter1.gif)
iTrader: (3)
Join Date: Apr 2014
Location: Huntington, Indiana
Posts: 2,885
Total Cats: 616
![Default](https://www.miataturbo.net/images/icons/icon1.gif)
Mine will be pre cooler so I can accurately compare temps to before the cooler was installed.
I have seen 245 or so oil temps on warmish days. I'd like to see no higher than 230 hot temps once the.cooler is installed.
The multi sender switch deal is intriguing but will have to wait until after my NZ expat adventure I think. Last project for the car this year will be hooking up the oil cooler.
I have seen 245 or so oil temps on warmish days. I'd like to see no higher than 230 hot temps once the.cooler is installed.
The multi sender switch deal is intriguing but will have to wait until after my NZ expat adventure I think. Last project for the car this year will be hooking up the oil cooler.
#1018
Elite Member
Thread Starter
iTrader: (37)
Join Date: Apr 2010
Location: Very NorCal
Posts: 10,448
Total Cats: 1,900
![Default](https://www.miataturbo.net/images/icons/icon1.gif)
I got a new shoe today!
![](https://www.miataturbo.net/attachments/build-threads-57/136991d1427836930-nothing-see-here-just-project-sisyphus-move-along-boot.jpg)
Good news is no surgery, bad news is that I get the boot for the next month. This will of course prevent me from driving the Miata or the Subaru. Bugger.
![](https://www.miataturbo.net/attachments/build-threads-57/136991d1427836930-nothing-see-here-just-project-sisyphus-move-along-boot.jpg)
Good news is no surgery, bad news is that I get the boot for the next month. This will of course prevent me from driving the Miata or the Subaru. Bugger.
#1020
Elite Member
Thread Starter
iTrader: (37)
Join Date: Apr 2010
Location: Very NorCal
Posts: 10,448
Total Cats: 1,900
![Default](https://www.miataturbo.net/images/icons/icon1.gif)
Man, I'm getting the RoboCop comments from everywhere with this thing
Poor Miss Lola kitty won't come anywhere near the boot though :(
Inactivity has forced me to start ordering the last couple pieces I need for the engine and turbo plumbing just to keep myself from going stir crazy. As a result I've got an inbox full of tracking numbers this afternoon, including one for a 49lb package from Lake Forest, CA
![Giggle](https://www.miataturbo.net/images/smilies/gay.gif)
Inactivity has forced me to start ordering the last couple pieces I need for the engine and turbo plumbing just to keep myself from going stir crazy. As a result I've got an inbox full of tracking numbers this afternoon, including one for a 49lb package from Lake Forest, CA
![Party Kitty](https://www.miataturbo.net/images/smilies/birthday[1].gif)
